Ruian Great Printing and Packaging Machinery CO.,LTD

Innovative highlights of the exhibit：

Internet of things remote control, hot knife slitting without tail film servo motor control feeder double electromagnetic heating system drying roller diameter 1000mm and heating roller diameter 380mm.

Product introduction:

Servo Motor Feeder, 4 suckers for lifting and 4 suckers for conveying structure. Max Speed 12000 sheets/h The conveying table adopts customized stainless steel corrugated board，The brush wheel and rubber pressing wheel move smoothly Servo motor overlap, improve accuracy of lap, error≤±2mm Machine host adopt double electromagnetic heating system, heating up and cooling down fast, temperature stability Gluing system Teflon process treatment, easy to clean and non-sticky Hot knife low pressure direct heating and slitting without tail film, detecting paper thickness and slitting, accurate and efficient The non-stop collector height can reach 1300mm, adpot non-stop collecting system, No need to stop and restart, saving time.

Innovative highlights of the exhibit：

High Speed Laminator, Max Speed can be reached 110m/min

Product introduction:

High Speed Feeder, 4 suckers for lifting and 4 suckers for conveying structure. Max Speed 12000 sheets/h, The height of non-stop feeding can reach 1300mm The conveying table adopts customized stainless steel corrugated board，The brush wheel and rubber pressing wheel move smoothly Servo motor overlap, improve accuracy of lap, error≤±2mm The machine host adopts the Internet of Things remote control system, the touch screen control panel is upgraded The paper cutter is equipped with a tension controller and an anti-curl device to ensure that the paper is flat and not curled The paper cutting part contains grinding wheel, disc knife and hot knife for slitting,matching bounce roller which is controlled by an independent motor, and the paper can be separated by using the speed difference The automatic collector height can reach 1300mm, adopt pneumatic paper sorting structure to ensure the neatness of the paper and facilitate the next process.

Innovative highlights of the exhibit：

The machine is equipped with JIALITE independently developed air knife device as standard, which is suitable for paper work of 80-600gsm, standard configuration IR and UV drying oven suitable for water based oil and uv oil drying.

Product introduction:

High Speed Feeder, 4 suckers for lifting and 4 suckers for conveying structure. Max Speed 12000 sheets/h, Double or multi-sheet detection device The conveying table adopts customized stainless steel corrugated board, The brush wheel and rubber pressing wheel move smoothly Three rollers reversing speed control head to ensure the water-based varnishing effect without streak printing, The metering rollers are individually motor driven to ensure even gluing,Improved air knife technology for thin paper (80-600g) to ensure that the paper does not attach to the roller after coating and runs smoothly. Infrared oven comes standard with 18 1.2kw infrared lamps UV oven comes standard with 3 8kw UV lamps Fan cooling device The automatic paper delivery device has a delivery height of up to 1300mm, and adopts a pneumatic paper management structure to ensure that the paper is neat.
